NEW LIBERTY DOUBLE STANDING SEAM ROOF PANEL ROLLFORMING MACHINE SS4E-15
New double standing seam roof panel Rollforming machine ss4e-15
Specifications
Length: 5' 4" (1.6m)
Width: 3' 5" (1.1m)
Height: 1' 9" (0.5m)
Weight 1000 lbs. (455 kg)
Speed: 30 ft/min (9m/min) approx.
Drive: polyurethane and lower steel forming rollers
Shear: manually powered, entrance end slitter
Coil width: 15” to 28" (380mm to 711mm)
Materials formed
Steel 30 gauge to 24 gauge (.3mm to .6mm)
(painted, galvanized, aluminized)
Aluminum .019" to .032" (.5mm to 08mm)
Copper 16 oz. To 20 oz. 3/4 hard
(.5mm to .7mm)
Standard features
Polyurethane and bottom forming drive rollers
Hard chrome steel forming roller system
Easy to operate entrance end manual slitter cutoff
Portable dongle for ease of operation
Width adjusted with simple crank
Wireless remote control
Length control with limit switch
Clip relief roller set included
Double bead roller set
1.5 hp electric motor
Welded tubular steel frame
One year limited parts warranty
