NEW GMC 10' x 14 Ga. - CNC SHEET METAL FOLDER
10' x 14 Ga. - CNC Sheet Metal Folder Specifications:
ISO 9001 certified Designed in US and Taiwan quality Machine Meet OSHA and CE safety standard ESA CNC control, made in Italy Max. 99 bends per program Up to 2000 Programs Storage Profiles library with graphics Programmable Radius Bend Programmable Angle/ Angle Correct 48” CNC back gauge with table and fingers Hardened nose bar and table, up to 48HRC Comes with one 1” Insert Bar and one ½” Insert Bar Yaskawa Servo motors and Drives Schneider electrical components All steel construction for maximum rigidity Hydraulic logic system centrally located and quiet Meet OSHA standard, to start the program, need to press foot pedal twice Safety type foot pedal with handle and E-stop switch Safety 24V low voltage & overload protection One year industrial warranty for parts Standard Features:
Capacity:
Mild Ste:
14Ga. Stainless Steel:
18Ga. Close hemming:
22Ga. Open hemming:
22Ga. Bending Length Capacity 10'1" Bend Angle Degree, programmable 0-135 degree Hemming capacity, mild steel:
20Ga. Hemming capacity, stainless steel:
24Ga. Large Beam Opening/clamping opening:
4 7/8" Min. Reverse Bend:
1/2" Max, Table Back Gauge Distance:
48 3/8" Min. Table Back Gauge Distance:
1/2" Back Gauge Repeatability:
0. 0039" Back Gauge Table Height 35 3/4" Motor for Bending Leaf:
4HP, 220V, 3PH Servo motor for back gauge:
2HP, 220V, 3PH Clamping Motor:
1 1/2HP, 220V, 3PH Machine Weight:
8,850 LBS Machine Size (LxWxH):
158" x 79" x 63"
